Product Description
Shank Model | Hole Size | Face Structure | Gauge Button | Front Button | Spline | Flushing Hole | Weight | |
mm | inch | Size*No. | Size*No. | KGs | ||||
WTRC3H | 90 | 3 1/2 | Concave | Φ12*6 | Φ10*4 | 6 | 2 | 8 |
95 | 3 3/4 | Drop Center | 8.5 | |||||
102 | 4 | 9 | ||||||
WTRC4 | 115 | 4 1/2 | Drop Center | Φ14*8 | Φ14*4+ Φ13*2 | 8 | 2 | 10 |
121 | 4 3/4 | Φ16*8 | Φ14*8 | 11 | ||||
127 | 5 | 12 | ||||||
WTRC4HA | 121 | 4 3/4 | Drop Center | Φ14*8 | Φ14*4+ Φ13*4 | 8 | 2 | 11 |
127 | 5 | Φ14*8 | Φ14*6+ Φ13*4 | 11.5 | ||||
133 | 5 1/4 | Φ16*8 | Φ14*11 | 12 | ||||
WTRC5A | 133 | 5 1/4 | Drop Center | Φ16*8 | Φ14*11 | 8 | 2 | 14 |
137 | 5 3/8 | 14.5 | ||||||
140 | 5 1/2 | 15 | ||||||
WTRC5HA | 140 | 5 1/2 | Drop Center | Φ16*8 | Φ16*6+ Φ14*5 | 8 | 2 | 17.7 |
146 | 5 3/4 | 19.2 | ||||||
152 | 6 | 20 | ||||||
WTRC6 | 152 | 6 | Drop Center | Φ16*8 | Φ16*8 | 8 | 2 | 20 |
159 | 6 1/4 | 22 | ||||||
165 | 6 1/2 | Φ18*4+ Φ16*4 | 25 | |||||
WTRC8 | 203 | 8 | Drop Center | Φ18*10 | Φ18*8+ Φ16*6 | 10 | 2 | 45 |
210 | 8 1/4 | 48 | ||||||
216 | 8 1/2 | Φ18*8+ Φ16*8 | 52 | |||||
WTRC12 | 305 | 12 | Drop Center | Φ19*12 | Φ19*9+ Φ19*12+ Φ16*10 | 12 | 3 | 142 |
313 | 12 1/4 | 145 | ||||||
320 | 12 5/8 | 150 | ||||||
